M50NiL
M50NiL is a carburizing, low carbon, high-nickel variant of M50 bearing steel known for its core fracture toughness, rolling contact fatigue resistance, heat resistance, and high surface strength.
Melt-type(s): VIM-VAR
Other name(s): CBS-50 NiL™
Comparable grade(s): M50, 9310
STANDARDS
| Type | Specifications |
|---|---|
| AMS | AMS 6278, AMS 2300, AMS-STD-2154 |
| UNS | K91231 |
| EN/DIN | 13MoCrNiV42-16-14, E13DCNV40 |
| EN | 1.3555 |
SIZES AVAILABLE
| Form | Size range |
|---|---|
| Bar | 0.7806" - 8.000" |
CHEMICAL COMPOSITION
| Element | Range (%) |
|---|---|
| C | 0.13 |
| Cr | 4.20 |
| Fe | 86.37 |
| Mn | 0.25 |
| Mo | 4.25 |
| Ni | 3.40 |
| Si | 0.20 |
| V | 1.20 |
CHARACTERISTICS
| High temperature | Stainless | Through-hardened | Nitriding | Carburizing | Induction |
|---|---|---|---|---|---|
CHARACTERISTICS
| Characteristic | Value |
|---|---|
| High temperature | |
| Stainless | |
| Through-hardened | |
| Nitriding | |
| Carburizing | |
| Induction |
ADDITIONAL INFO
Heat Treatment
Heat treatment instructions and recommendations for M50NiL are provided by one of our mills, Carpenter. Please contact Sullivan Steel for additional guidance or information.
Machinability
Sullivan Steel typically stocks M50NiL in the annealed condition, optimal for machinability and heat treatment uniformity. Exceptions may apply.
Common Applications
High-performance bearings and gears.
RESOURCES
Carpenter Data Sheet: CBS-50 NiL.pdf
DISCLAIMER
The product information provided on this page is provided for general reference only and is not complete. Customers and prospective customers should rely on the applicable material certifications for product information, including any exceptions to specifications, if applicable. Material certifications are available upon request. All product sales are subject to Sullivan Steel’s standard terms and conditions of sale.
